Medical Sterilizer Machine Hospital Sterilization Equipment 3 Times Pulse Vacuum
Hospital Sterilization Equipment Technical Data
|
Model
technical data
|
BT-35HV |
BT-50HV |
BT-75HV |
BT-100HV |
| Chamber volume |
35L(φ318×450)mm |
50L
(φ340×550)mm
|
75L(φ400×600)mm |
100L(φ440×650)mm |
| working pressure |
0.22MPa |
0.22MPa |
0.22MPa |
0.22MPa |
| Working temperature |
134℃ |
134℃ |
134℃ |
134℃ |
| Heat average |
≤±1℃ |
≤±1℃ |
≤±1℃ |
≤±1℃ |
| Timer |
0～99min |
0～99min |
0～99min |
0～99min |
| Adjustment of temperature |
105～134℃ |
105～134℃ |
105～134℃ |
105～134℃ |
| Power |
2.5KW /AC220V.50Hz |
3.K0W/AC220V.50Hz |
4.5KW /AC220V.50Hz |
4.5KW /AC220V.50Hz |
| Overall dimension |
600*410*1030(mm) |
690×470×1140(mm) |
730*510*1270(mm) |
730*550*1305(mm) |
| Transport dimension |
730*500*1170(mm) |
760×550×1290(mm) |
820*600*1380(mm) |
840*640*1410(mm) |
| G.W/N.W |
96Kg/ 77Kg |
120Kg/ 100Kg |
140Kg/ 118Kg |
160Kg/ 128Kg |
Hospital Sterilization Equipment Characteristics:
1. Automatically controlled by computer, digital display of working status, touch type key.
2. Dynamically showed the temperature, pressure time and vacuum rate and the full cycle
3. fully automatically route for water inlet, pulse vacuum,heating, sterilizing, draining, exhausting, vacuum drying.
4. 3 times pulse vacuum,which make the vacuum rate as -0.081mpa,and ensure the high extracting of inner air from dressing, A.B type hollowed appliance.
5. with 4 fixed program for appliance, medical dressing, rubbers and fluid,and the user can also set the program as they need.
6. equipped with the PT/TT testing connector, easy to run the testing.
7. Multiple pulse vacuum drying after sterilizing, ensure the nice sterilizing.
8. Equipped with bacteria filter, ensure the sterile air enter the inner vacuum environment,avoid the second contamination.
9. hand wheel type of quick-open door structure,self-inflating type seal.
10. adopted with immersed heating, with high heating efficiency.
11. steam-water inner circulation system:no steam discharge, and the environment for sterilizing will be clean and dry.
12. automatically shut off with beep reminding after sterilization.
13. fully high quality stainless, equipped with double stainless steel basket.
Hospital Sterilization Equipment Advantage
- 3-Stage Pulse Vacuum Technology – Ensures deep air removal for optimal steam penetration, achieving 100% sterilization even for complex instruments.
- Hospital-Grade Efficiency – Meets international standards (ISO 17665, AAMI, EN 13060) with rapid cycles (e.g., 134°C/273°F at [X] psi).
- Automated Safety Controls – Features auto-lock lids, pressure/temperature sensors, and alarms for fail-safe operation.
- Versatile Compatibility – Suitable for wrapped/unwrapped instruments, textiles, and hollow devices (e.g., lumens, cannulas).
- Durable & Low-Maintenance – Full stainless steel chamber and corrosion-resistant components for long-term clinical use.
Purpose of Medical Sterilizer Machine:
This equipment is designed to eliminate all microbial life (bacteria, viruses, spores) from surgical tools, dental instruments, and laboratory gear, ensuring infection-free healthcare environments. It is widely used in:
- Hospitals & Clinics – For reusable surgical/medical devices.
- Dental Labs – Sterilizing drills, scalers, and implants.
- Pharmaceuticals & Research – Preparing sterile media and equipment.
